There are many available on the web, here is an example of an easy to configure proxy for Windows with a download link and configuration instructions – Īnother way to run a stratum mining proxy is by using bfgminer on a raspberry pi with Mine Peon Reset The Blade requires the use of a stratum mining proxy in order to receive work. The “Ports” and “Server Addresses” fields are used for connecting to local proxy discussed in the next section. For example, the “Ports” field can have the value 6332,6332 as a valid entry.
The three fields labeled “Ports”, “Server Addresses”, and “user:pass” require a primary and secondary value in the format Note that if your home network is using a different configuration than the typical 192.168.1.x setup, you will need to either temporarily reconfigure your home network, or to connect the blade and computer to a separate router in order to reconfigure the blade to be compatible with your existing network. Once the blade has been powered on and connected via ethernet, you can access the web configuration page by clicking on this link. The default IP address for the blade is 192.168.1.254 and the default port for the web configuration is 8000. Plug in power supply and re-attach power jumper. Repeat this step for each additional blade you install. The blade’s heatsink grill should be facing the power supply. It is important that the blade be in the correct orientation.
If you are inserting multiple blades we recommend you start with the slot closest to the power supply. Make sure power supply is fully inserted. This is just to make sure you do not accidentally power things up before you are ready. Remove the ‘power jumper’ on the backplane. To set up power for a blade with a backplane: Putting something in the wrong direction may fry your Blade. Note: Orientation of components is important. (1) 1000w HP hot-swap style server power supply Now connect all components together and turn it on.
To do this you will bridge the green wire with a black wire on the 24 port connector using a paper clip. If you are not using the power supply for anything else, then you will need to jumper a couple of ports on the 24 port connector in order to imitate the ‘On’ switch. With the green adapter screws facing you, the cable orientation is: Black (GND), Black (GND), blank, Yellow (12V). The most standard approach to power blades is to use a 4-port molex connector from a standard computer power supply.Ĭlip the two black (GND) and one yellow (12V) cable from the male end and strip the cablesĬonnect to the 4-port green power connector. (1) molex extension cable or splitter Įach blade consumes approximately 75W each of 12V power and have a custom 4-port power connector. (1) standard computer power supply with a 4-port molex connector (1) 4-port green power connector Power Setup (Without Backplane): You may need to run a client on a local computer in order to translate the getwork protocol from the blade to the stratum protocol supported by most mining pools. If you are interested in purchasing blades or supporting components see our store at Įach blade requires a power source and separate ethernet connection. This guide provides instructions and information about the second version (Rev 2) of the product. ASICMiner has produced two versions of it’s Blade product.
